Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 179
[USER3]
Displays the runtime of the light source with [OPERATING MODE] set to [USER3].
[CONSOLIDATED RUNTIME]
*3
Converts the total runtime of the light sources with [OPERATING MODE] set to each item into the
time used with the [NORMAL] setting.
The consolidated runtime is used for a rough indication about when to perform maintenance when the
projector is used in combination of each item in [OPERATING MODE].
[ANGLE INFORMATION]
[ROLL ANGLE]
*4
Displays the horizontal swing angle based on the detection result of
the built-in angle sensor.
[PITCH ANGLE]
*4
Displays the vertical tilt angle based on the detection result of the
built-in angle sensor.
[SIGNAL INFORMATION]
[INPUT]
Displays the input terminal used for the projected image.
Displays the representative input terminal when one image is
displayed with multiple input signals.
[SIGNAL FORMAT]
Displays the format of the input signal.
[LINK]
Displays the [SDI LINK] setting.
Displays the determination result of the signal when [AUTO] is set.
[4K DIVISION]
Displays the [4K DIVISION] setting.
Displays the determination result of the signal when [AUTO] is set.
[SAMPLING]
Displays the sampling information and the color format of the input
signal.
[BIT DEPTH]
Displays the gradation of the input signal.
[SIGNAL LEVEL]
Displays the signal level of the input signal.
[GAMMA]
Displays the [GAMMA] setting.
[COLOR SPACE]
Displays the [COLOR SPACE] setting.
*1 The temperature status is indicated with text color (green/yellow/red) and bar scale. Use the projector within the range that the indication is
green.
*2 [MEMORY NO.] and [NUMBER OF REGISTERED SIGNAL] will not be displayed when the [PROJECTOR SETUP] menu → [STORE TYPE]
is set to [SHARED].
*3 [CONSOLIDATED RUNTIME] can be obtained with the following calculation formula. Values obtained by the calculation formula contain a
slight error.
*4 The angle value displayed is relative to the benchmark (zero calibration reset state / zero calibration implementation state) selected on the
[ANGLE MONITOR] screen.
Conversion formula for [CONSOLIDATED RUNTIME]
A x 1.0 + B x 0.8
f A: Runtime of the light source with [OPERATING MODE] set to [NORMAL], [QUIET], [USER1], [USER2], or [USER3]
f B: Runtime of the light source with [OPERATING MODE] set to [ECO]
r [DETAILED INFORMATION]
[INPUT]
Displays the input used for the projected image.
[SIGNAL FORMAT]
Displays the format of the input signal.
[SIGNAL FREQUENCY]
Displays the frequency of the input signal.
[SCAN TYPE]
Displays the scan type of the input signal.
[TOTAL DOTS]
Displays the total dot count of the input signal.
[DISPLAY DOTS]
Displays the number of input signal display dots.
[TOTAL LINES]
Displays the total line count of the input signal.
[DISPLAY LINES]
Displays the number of input signal display lines.
[SAMPLING]
Displays the sampling information and the color format of the input signal.
[BIT DEPTH]
Displays the gradation of the input signal.
[SIGNAL LEVEL]
Displays the signal level of the input signal.
[COLORIMETRY]
Displays the color gamut information of the input signal. The content of display is as follows.
[ITU-2020]: When the color gamut is compliant with ITU-R BT.2020 standard
[ITU-709]: When the color gamut is compliant with ITU-R BT.709 standard
[SMPTE 170M]: When the color gamut is compliant with SMPTE 170M standard
[---]: When there is no signal, when the color gamut information is not included in the InfoFrame
information, or when the color gamut information other than [ITU-2020], [ITU-709], or [SMPTE 170M] is
included
[HDCP STATUS]
Displays the HDCP status of the input signal. The content of display is as follows.
[HDCP2.X]: When protected with HDCP 2.2 or HDCP 2.3
[HDCP1.X]: When protected with HDCP 1.X
[NONE]: When not protected with HDCP
[---]: When there is no signal
[SDI ERROR STATUS]
Displays the error status of the SDI input.
To Next Page
