Chapter 4 Settings — [PROJECTOR SETUP] menu
180 - ENGLISH
r [CONTENT INFORMATION]
[EOTF]
Displays EOTF (Electro-Optical Transfer Function) out of the InfoFrame information added to the input
signal.
[MASTERING DISPLAY
COLOR VOLUME]
[RED]
Displays the chromaticity coordinates for the primary color red out of the
InfoFrame information added to the input signal.
[GREEN]
Displays the chromaticity coordinates for the primary color green out of
the InfoFrame information added to the input signal.
[BLUE]
Displays the chromaticity coordinates for the primary color blue out of the
InfoFrame information added to the input signal.
[WHITE]
Displays the chromaticity coordinates for the white point out of the
InfoFrame information added to the input signal.
[MAX LUMINANCE]
Displays the maximum brightness out of the InfoFrame information added
to the input signal.
[MIN LUMINANCE]
Displays the minimum brightness out of the InfoFrame information added
to the input signal.
[CONTENT LIGHT LEVEL]
[MaxCLL]
Displays MaxCLL (Maximum Content Light Level) out of the InfoFrame
information added to the input signal.
[MaxFALL]
Displays MaxFALL (Maximum Frame Average Light Level) out of the
InfoFrame information added to the input signal.
Note
f While the [STATUS] screen is displayed, press the <DEFAULT> button to check the details of the temperature information of each part
inside the projector.
For details of operation, refer to “Displaying the details of the temperature information” (x page 180).
f If any abnormality has occurred on the projector, press the <DEFAULT> button while the [STATUS] screen is displayed to check the details
of the error information.
f For details on the contents displayed in [SELF TEST], refer to “Self-diagnosis display” (x page 276).
f The values displayed in [ANGLE INFORMATION] are based on the results of the angle sensor detection and may di󰀨er from the actual tilt
angle of the projector. The displayed values are for reference only and accuracy is not guaranteed.
f The relationship between the value displayed in [ROLL ANGLE] and the projector tilt status is shown as below. This is the case when
[PITCH ANGLE] is [0°] and [ANGLE MONITOR] is set to zero calibration reset state.
g [-1°] ~ [-30°]: The projector swings counterclockwise with the top surface facing upward and the screen set in front.
g [0°]: The projector is horizontal with the top surface facing upward.
g [+1°] ~ [+30°]: The projector swings clockwise with the top surface facing upward and the screen set in front.
g [-179°] ~ [-150°]: The projector swings clockwise with the top surface facing downward and the screen set in front.
g [+180°]: The projector is horizontal with the top surface facing downward.
g [+179°] ~ [+150°]: The projector swings counterclockwise with the top surface facing downward and the screen set in front.
f The relationship between the value displayed in [PITCH ANGLE] and the installation attitude of the projector is shown as below. This is the
case when [ROLL ANGLE] is [0°] in the zero calibration reset state.
g [-1°] ~ [-30°]: The projector swings with the top surface facing upward and the projection lens side facing downward.
g [0°]: The projector is horizontal with the top surface facing upward.
g [+1°] ~ [+30°]: The projector swings with the top surface facing upward and the projection lens side facing upward.
g [-179°] ~ [-150°]: The projector swings with the top surface facing downward and the projection lens side facing downward.
g [+180°]: The projector is horizontal with the top surface facing downward.
g [+179°] ~ [+150°]: The projector swings with the top surface facing downward and the projection lens side facing upward.
f If you press the <ENTER> button while displaying [ANGLE INFORMATION] page of the [STATUS] screen (5/6 page), the [ANGLE
MONITOR] screen which graphically displays the tilt angle of the projector is displayed. For details of [ANGLE MONITOR] screen, refer to
“[ANGLE MONITOR] screen” (x page 181).
f If you press the <ENTER> button while displaying [SIGNAL INFORMATION] in the page 6/6 of the [STATUS] screen, the [DETAILED
INFORMATION] screen can be displayed to view the detailed information of the input signal. Information for multiple input signals may be
displayed depending on the projected image. Press qw to switch pages.
f While the [DETAILED INFORMATION] screen is displayed, press the <ENTER> button to display the [CONTENT INFORMATION] screen,
and the contents of the InfoFrame information added to the input signal can be displayed.
f There are items that are displayed or not displayed in [SIGNAL INFORMATION], [DETAILED INFORMATION], and [CONTENT
INFORMATION] depending on the setting and the signal being input.
Displaying the details of the temperature information
Details of the temperature information of each part inside the projector can be checked.
1) Press the <DEFAULT> button while the [STATUS] screen is displayed.
f The selection screen is displayed.
2) Press as to select [TEMPERATURE INFORMATION].
f The items will switch each time you press the button.
[ERROR INFORMATION]
Displays the detailed screen of the error information.
[TEMPERATURE INFORMATION]
Displays the detailed screen of the temperature information.
