Chapter 5 Operations — Using the web control function
236 - ENGLISH
Status display icon
[Geometry]
The [POSITION] menu → [GEOMETRY] is set to [OFF].
The [POSITION] menu → [GEOMETRY] is set to [KEYSTONE].
The [POSITION] menu → [GEOMETRY] is set to [CORNER
CORRECTION].
The [POSITION] menu → [GEOMETRY] is set to [CURVED
CORRECTION].
The [POSITION] menu → [GEOMETRY] is set to [PC-1].
The [POSITION] menu → [GEOMETRY] is set to [PC-2].
The [POSITION] menu → [GEOMETRY] is set to [PC-3].
[Lighting]
Corresponding light source is illuminated.
Corresponding light source is not illuminated.
[Error]
The light source is in warning status.
The light source is in error status.
The temperature is in warning status.
The temperature is in error status.
A warning other than light source or temperature has occurred.
An error other than light source or temperature has occurred.
To Next Page
