P Series User Guide 18
Motor Output Power PD-04 PD-10 PD-35
Shaft Power
@Continuous Current
400 Watts 1,000 Watts 3,500 Watts
Shaft Power
@ Peak Current
1,200 Watts 3,000 Watts 10,500 Watts
Drive Output Power
Continuous Current
(RMS)
3.0 Amps 6.75 Amps 16.7 Amps
Peak Current (RMS)
9.0 Amps 20.25 Amps 50.1 Amps
Drive Input Voltage
120/230 VAC, 1Ø,
230 VAC, 3Ø,
50/60Hz
230 VAC,1/3Ø,
50/60Hz
230 VAC, 1/3Ø,
50/60Hz
Drive Control Voltage
120/230 VAC, 1Ø,
50/60Hz
230 VAC, 1Ø,
50/60Hz
230 VAC, 1Ø,
50/60Hz
Table 2. Output Power Level
1.1.4 Front panel description of representative drives
Figure 2. 400W Drive Front Description
