P Series User Guide 133
0x2209
-
Digital Input Signal 10 Selection
UINT
RW
No
-
0x220A
-
Digital Input Signal 11 Selection
UINT
RW
No
-
0x220B
-
Digital Input Signal 12 Selection
UINT
RW
No
-
0x220C
-
Digital Input Signal 13 Selection
UINT
RW
No
-
0x220D
-
Digital Input Signal 14 Selection
UINT
RW
No
-
0x220E
-
Digital Input Signal 15 Selection
UINT
RW
No
-
0x220F
-
Digital Input Signal 16 Selection
UINT
RW
No
-
0x2312
-
Multi-Step Operation Speed 1
INT
RW
No
-
0x2313
-
Multi-Step Operation Speed 2
INT
RW
No
-
0x2314
-
Multi-Step Operation Speed 3
INT
RW
No
-
0x2315
-
Multi-Step Operation Speed 4
INT
RW
No
-
0x2316
-
Multi-Step Operation Speed 5
INT
RW
No
-
0x2317
-
Multi-Step Operation Speed 6
INT
RW
No
-
0x2318
-
Multi-Step Operation Speed 7
INT
RW
No
-
0x2319
-
Multi-Step Operation Speed 8
INT
RW
No
-
0x231A
-
Velocity Command Switch Select
UINT
RW
No
-
0x2227 -
Analog Velocity Command Filter
Time Constant
UINT RW No -
0x2229
-
Analog Velocity Command Scale
INT
RW
No
-
0x222A -
Analog Velocity Command Clamp
Level
UINT RW No -
Table 75. Related Objects for Velocity Control
6.4.2 Function Set of Velocity Command Switch
Analog speed command when the contact is on after setting the value, 1 or 2.
Ex 1) Set value is 2 and, Input Analog command 10[V] in the state that SPD1 and SPD2
are on.
Operating motor speed is 100[rpm] and not available analog input command
speed.
Operating speed is operated by multistep command speed in the set value of
parameter 0x2315.
Ex 2) Set value is 2 and, Input Analog command 10[V] in the state that SPD1, SPD2 and
SPD3 are on.
Operating motor speed is 1000[rpm] and not available digital input command
speed.
Operating speed is operated by analog speed command voltage in the set value of
parameter 0x2229.
Set Value
Setting Details
0 Use Analog speed command
1
Use input contact SPD1, SPD2 and Analog command speed.
2
Use input contact SPD1, SPD2, SPD3 and Analog speed command
3
Use input contact SPD1, SPD2, SPD3 Speed
