Parker P Series - I;O Signal Setting; Allocating Digital Input Signals; Table 54. Encoder Output Signal of Open Collector Method; Table 55. Encoder Output Related Objects

Parker Hannifin
P Series User Guide 95
Table 54. Encoder Output Signal of Open Collector Method
 Related Objects
Index
Sub
Index
Name
Variable
Format
Accessibility
PDO
Allocation
Unit
0x3006 - Encoder Output Pulse UDINT RW No Pulse/rev.
0x3007 - Encoder Output Mode UINT RW No -
Table 55. Encoder Output Related Objects
4.5 I/O Signal Setting
4.5.1 Allocating Digital Input Signals
You can set the functions of digital input signal of I/O connector and input signal level.
Among the 28 input functions listed below, you can allocate the functions that you
want to use to digital input signals 1 through 16 at your discretion.
