Pegasus M852-13 - M832 糸道標準取付位置; M832 Positioning the Thread Guides

3
7
1
1
5
4
1
A
3
7
3
7
1
5
4
1
1
5
4

Align the center of the screw
with that of the slot.
M832-38, -48, 48P2,-70

516
Stitch type
:
516
M832-355

514+401
Stitch type: 514+401

Bottom of needle stroke

Top of needle stroke

1

Align the end of the eyelet with the ridge line of 1.

Bottom of needle stroke

Top of needle stroke

highest position

highest position
1 
Align the center of the eyelet with the ridge line of 1.
A
Align with line A.
M832-86
516 ()
Stitch type: 516 (for jeans)

Bottom of needle stroke

Top of needle stroke

1

Align the end of the eyelet with the ridge line of 1.
M832 
M832 Positioning the thread guides
Fig.32
図 32

