Pentair EASYTOUCH PL4 User Manual

64
EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
Symptom Possible Cause Solution
Unitseemstoturnonoroff
circuitswithouttheuser/
transmitter
Anearbyhomeis
operatingasimilar
wirelessunit
Selectanalternateaddresscodeforthetransmitter
andreceiver.Changetheswitchesonbothreceiverand
remotetoanalternate,butmatchingsetting.
Unitdependablyturns
equipmentON,butonceequip-
mentisrunningitdoesnotde-
pendablyturnequipmentOFF,
orrangeisgreatlyreduced
whenequipmentisrunning.
Undueelectricalnoise
isbeingproducedby
oneormorepieces
ofequipmentinclose
proximitytothereceiver.
RelocatetheReceiverawayfromequipmentsuchas
blowermotors.Relocatethereceiverinalocationthat
providesfewerobstructionstotheareatheusercom-
monlyoperatesthetransmitter.
Unitoperates,buthasgreatly
reducedrangecomparedto
priorfunction
TransmitterBatteryis
failing.
ReplaceTransmitterbattery(type20323V).
Problem: TheQuickTouch
®
IIWirelessRemotewillnotwork,orwillnotworkdependably
(Continued).
EasyTouch PL4/PSL4 Control System Wiring Diagram
(Outdoor Control Panel)
PL4/PSL CONTROL SYSTEM
FOR POOL AND SPA
WIRING DIAGRAM
