Workshop Manual, TSD3450E, Issue 1 19
2800
Recommended torque figures
Exceptions to these torque figures are given in the Workshop Manual where necessary.
Before any components are fitted to the engine, ensure that they are in a new or close to new condition. Bolts
or threads must not be worn or damaged. Components must be free from rust or other corrosion. Clean with
a non-corrosive cleaner if necessary. Do not lubricate the threads of fasteners. Rust preventative which has
been applied by the component supplier for shipping and storage is acceptable. Certain components may
require an application of a particular lubricant, details are given in the Workshop Manual where relevant.
Standard torque figures for metric fasteners
Metric nuts and bolts
Thread size
metric
Standard torque
M6 12 +/- 3 Nm (9 +/- 2 lbf ft)
M8 28 +/- 7 Nm (21 +/- 5 lbf ft)
M10 55 +/- 10 Nm (41 +/- 7 lbf ft)
M12 100 +/- 20 Nm (75 +/- 15 lbf ft)
M14 160 +/- 30 Nm (120 +/- 22 lbf ft)
M16 240 +/- 40 Nm (175 +/- 30 lbf ft)
M20 460 +/- 60 Nm (340 +/- 44 lbf ft)
M24 800 +/- 100 Nm (590 +/- 75 lbf ft)
M30 1600 +/- 200 Nm (1180 +/- 150 lbf ft)
M36 2700 +/- 300 Nm (2000 +/- 220 lbf ft)
Metric taperlock studs
Thread size
metric
Standard torque
M6 8 +/- 3 Nm (6 +/- 2 lbf ft)
M8 17 +/- 5 Nm (13 +/- 4 lbf ft)
M10 35 +/- 5 Nm (26 +/- 4 lbf ft)
M12 65 +/- 10 Nm (48 +/- 7 lbf ft)
M16 110 +/- 20 Nm (80 +/- 15 lbf ft)
M20 170 +/- 30 Nm (125 +/- 22 lbf ft)
M24 400 +/- 60 Nm (300 +/- 44 lbf ft)
M30 750 +/- 80 Nm (550 +/- 60 lbf ft)
M36 1200 +/- 150 Nm (880 +/- 110 lbf ft)
