Workshop Manual, TSD3450E, Issue 1 131
2800
Flywheel housing
To remove and to fit Operation 13-2
Special requirements
To remove
1 Remove the flywheel, Operation 13-1.
2 Remove the crankshaft rear seal and wear sleeve, Operation 5-3.
3 Remove the starter motor, Operation 14-1.
4 Remove the sump, Operation 10-3.
5 Use a suitable hoist to support the flywheel housing and remove the bolts (A1 to A24) which retain it.
Note: The bolts which retain the flywheel housing are of two different sizes. Make a note of their positions to
ensure that they are fitted correctly.
6 Remove the flywheel housing from the dowels in the crankcase. The weight of the flywheel housing is
approximately 83 kg (183 lb).
Consumable products
Description Part number
Liquid gasket CH10879
