12
128 Workshop Manual, TSD3450E, Issue 1
2800
To test the pressure of the coolant pump Operation 12-15
Special requirements
1 To check that the coolant pump is operating correctly, the outlet pressure can be measured.
2 Remove the plug (A1) from the coolant manifold and connect the pressure gauge, GE50033, to the port.
3 Start the engine and run the engine until the normal temperature of operation is obtained.
4 Make a note of the reading on the pressure gauge. The pressure supplied by the coolant pump should be
112 +/- 12 kPa (16 +/- 2 lbf/in
2
).
Special tools
Description Part number
Pressure gauge GE50033
