11
Workshop Manual, TSD3450E, Issue 1 105
2800
Fuel transfer pump
To remove and to fit Operation 11-2
To remove
1 Disconnect the fuel pipes from the fuel transfer pump (A2).
2 Use plugs or caps to seal temporarily all openings to prevent contamination of the fuel system.
3 Remove the bolts (A1) and withdraw the fuel transfer pump.
To fit
1 Check the condition of the ‘O’ ring seal on the fuel transfer pump, renew the seal if it is worn or damaged.
2 Ensure that the ‘O’ ring seal is fitted correctly to the fuel transfer pump. Apply a small amount of clean engine
oil to the seal.
3 Fit the fuel transfer pump (A2) and retain with two bolts (A1).
4 Remove the plugs or caps from the fuel pipe openings and connect the fuel pipes.
5 Eliminate air from the fuel system, Operation 11-6.
