Workshop Manual, TSD3450E, Issue 1 43
2800
Valve guides
To remove and to fit Operation 3-9
Special requirements
To remove
1 Remove the cylinder head, Operation 3-5.
2 Remove the valves, Operation 3-7.
3 Use the special tool (A1), GE50043, and a hammer to drive the valve guide (A2) from the cylinder head.
Special tools
Description Part number
Removal/installation tool GE50043
Sleeve GE50044
