3–9
3-point emergency lock retractor
type seat belts (ELR)
To fasten belt
Pull the seat belt from the retractor and insert
the tongue plate into the buckle until it clicks.
NOTE
If the seat belt lock is pulled, try releasing
the seat belt and gently pulling it again. If
this fail, pull the seat belt with force and
release it. Gently
pull the seat belt again
to fasten.
w WARNING
For full restraint, make sure, after
inserting the tongue plate, the
connection is securely locked and
the belt is not twisted.
Plate
Plate
Button
Button
Buckle
Buckle
To adjust belt
Place the belt as low as possible on your
hips, not on your waist.
Pull the shoulder portion of the belt toward
the retractor to remove any slack.
It is not necessary to adjust the length of
the seat belt since it has been designed to
ensure that it normally extends and retracts
according to the movement of the body and
it may be locked in the case of emergency
(hard braking, collision, etc.).
Take up
slack
Correct
Too high
To unfasten belt
Push the buckle release button.
Allow the retractor to retract the belt
completely.
Make sure that the belt is not twisted as it is
being retracted.
NOTE
When using the rear center seat belt, make
sure to use the buckle with the CENTER
mark.
Push
