5–13
OFF
The light goes on when the ignition switch is
turned “ON” and goes off a few seconds later.
When the VSC is turned off, the indicator
light goes on.
To turn off VSC, push the VSC OFF button for
more than 3 seconds.
VSC OFF indicator light (If equipped)
TRC
OFF
The light goes on when the ignition switch is
turned “ON” and goes off a few seconds later.
When the TRC is turned off, the indicator
light goes on.
To turn off TRC, push the VSC OFF button.
TRC OFF indicator light (If equipped)
The light goes on when the ignition switch is
turned “ON” and goes off a few seconds later.
The slip indicator light will illuminate when
error is detected in VSC system.
CAUTION
If the light fails to illuminate or remain in
a go on state, even when the ignition is
turned to “ON” position, there may be a
system error. Have the system checked
by an authorised Perodua Service Centre
immediately.
Slip indicator light (If equipped)
