6–2
Right and left outlet ports
Use the knob to control the air direction.
This control dial changes the air outlet
positions.
Dial
position
Air outlet
D
Position in parentheses ( ) denotes an air
outlet where the air flow rate is very small.
Air outlet control dial Temperature control dial
Air temperature is adjusted with this dial.
Air conditioner system will switch "OFF" if
adjust at minimum position.
A / C
OFF
Min. cool Max. cool
