Frequency Management and Channel Selection
2-12 Installation
To fill in the frequency coordination forms, you'll need to know the following:
• The Frequency Range to be used: Two separate coordination submissions are
required: For the first one, click on the range of 1395.0 through 1400.0 MHz.
completed the registration. Then you will need to go through the process
again for the second frequency band. For the second one, click on all the
frequency ranges listed in the range of 1427.0 through 1432.0 MHz.
• The name/s of the Clinical Unit/s using the devices (e.g. ICU4, CCU-West, ER1,
Step-Down North, etc.)
• Latitude and longitude that represents the center of the area where the
transmitting devices will be deployed. Comsearch can help provide this
information; www.comsearch.com. Google Earth is an excellent site to use for
this information.
• County
• The radius of deployment, expressed in meters. The radius can be determined
by drawing an imaginary circle around the center of the clinical unit that
encloses/encompasses the unit.
• The number of the highest floor on which a transmitting device will operate.
• The number of transmitting devices will be used, i.e. the total number of MX40
devices, Access Points and Remote Antennas, etc. combined. For example: 12
MX40 and 15 AP – would translate to 27 devices MX40 C/D (selection on
Database)
• The Effective Radiating Power: 6.3 mW. (This will be automatically filled in
once the device is selected)
• The Equipment Manufacturer: Philips Medical Systems.
• The Equipment Models: MX40, etc. current devices are registered as C/D
version (A/B is for the older APs)
After completing the device registration and frequency coordination, a WMTS
Coordination Certificate is issued.
Important — Within 30 days, the installation date must be updated in the WMTS
registration system. The installation date cannot precede the certificate date.
1.4GHz Smart-hopping Channel Definition
1.4GHz Smart-hopping Channel Definition - Standard
Primary Low Center High
Channel 1: 1395.0977MHz 1395.8977MHz 1396.6977MHz
Channel 2: 1396.6970MHz 1397.4970MHz 1398.2970MHz
