Test Map
The test map shows which tests are required in which situations.
Service Event
(When performing...)
Test Blocks Required
......Complete these tests)
Installation of M3/M4 with no display
connected to the VGA output
Perform Visual and Power On test
blocks
Installation of M3/M4 with a display
connected to the VGA output
Perform Visual, Power On and
Safety (1) test blocks
Installation of M3/M4 with a recorder
connected to the serial interface
Perform Visual, Power On and
Safety (1) test blocks. Perform test
print on recorder.
Repairs where the power supply in the M3/
M4 is replaced
Perform Power On and Safety (2)
Test blocks
Repairs where the monitor has been
dropped
Perform Power On and Safety (2)
and (3) Test blocks
All other M3046A repairs, Hardware or
Software Upgrades
Perform Power On test block
Preventative Maintenance Perform all Preventative
Maintenance Tests
Safety and Performance Perform all Safety and Performance
Test blocks.
