Philips M3015A - Back of Monitor

A Quick Description of the Monitor
6
Introduction to the Instrument
Back of Monitor:
Mounting Plate
LAN/Software Update
Nurse Call Relay
Connector (≤36V)
Connector to
Catches for
attaching the
Measurement
Server
the Measurement
Server (≤48V)
Connector (≤5V)
Locking Mechanism for
the Measurement Server
Connector for an additional
display (VGA Interface) (≤3.3V)
P
rotective earth
c
onnector point
f
or additional display
