Refit Procedures for the M3015A Measurement Server Extension
Re
p
airin
g
the Instrument 237
Refit Procedures for the M3015A Measurement Server
Extension
Tools Required:
• A thin-bladed screwdriver.
• A pair of large tweezers.
• In addition, for refitting the Pump, you will need a large-bladed screwdriver.
WARNING There is high voltage inside the Instrument (800V). Do not connect the Measurement
Server Extension to a Monitor while the Extension housing is open.
As well, parts inside the Instrument may be contaminated with bacteria. Protect
yourself from possible infection by wearing examination gloves during these
procedures.
Refitting the CO
2
Scrubber
WARNING The CO
2
Scrubber contains lithium hydroxide monohydrate. This is a strong base. Do
not open or damage the CO
2
Scrubber. If you come into contact with the CO
2
Scrubber
material, flush the area immediately with water and consult a doctor.
To refit the CO
2
Scrubber, do the following:
Step 1 Feed the end of the CO
2
Scrubber through the bracket to meet the Extension intake
tube.
Step 2 Push the intake tube firmly into the scrubber end to connect it.
Step 3 Holding the body of the CO
2
Scrubber with tweezers, feed the CO
2
Scrubber fresh
air intake under the second bracket and position it.
