Philips M3015A - Support-Related Parts; Cables and MSL through Wall Installation Parts

Support-Related Parts
272 Re
p
lacement Parts
Support-Related Parts
Cables and MSL Through Wall Installation Parts
For further information on cabling, refer also to the IntelliVue Service Guides.
Part Number
12-Digit
Reordering
Number
Description
M3046-64107 453563333111 Service Link Bar
M1360-61675 453563277381 Cable for configuration of the M3 Wireless LAN Assembly
M319960102 453563337381 UTP Crossover Cable, orange (approx. 3.7m / 12ft
M3199-60104 453563337401 UTP Patch Cable (approx. 2.1m / 7.0ft)
Site Survey Tool N/A Site Survey Tool is available from Connectronics
(www.connectronics.com). The part number is 82-6332 7402-
05, Range LAN2/PCMCIA Card (One-piece with Snap-on
antenna)
Wireless Board
Configuration Tool
N/A The tool for the wireless board configuration is included on the
IntelliVue Information Center CD-ROM
M3080-10801 N/A VPS Recovery CD
Product Option
Number
Part Number
12 Digit
Reordering
Number
Description
Cables with both ends terminated with straight MSL connectors
M3081A #A11 M3081-61602 453563377851 2m Measurement Server to Monitor
M3081A #A12 M3081-61603 453563402731 4m Measurement Server to Monitor
M3081-61626 453563474781 0.75m Measurement Server to Monitor
(compatible IntelliVue cable)
Unterminated cables
M3081A #A15 M3081-61615 453563484481 15m MSL Istallation Cable (Through Wall)
M3081A #A25 M3081-61625 453563484491 25m MSL Istallation Cable (Through Wall)
Face Plates
M3081A #C06 M3081-68708 453563484531 MSL Face Plate, US Version (pair of connector
boxes)
M3081A #C07 M3081-68708 453563484541 MSL Face Plate, US Version (pair of connector
boxes)
Tools
M3086-43801 453563484771 Insertion Tool (LSA Plus Tool for connecting
cables)
Local Recorder Serial Cable
M3000-61613 453563484751 Serial interface cable for connecting the XE-50p
local recorder
