Temperature and Invasive Blood Pressure (Temp/Press) measurement
Introduction to the Instrument
37
Temperature and Invasive Blood Pressure (Temp/Press)
measurement
Description
The Measurement Server has a measurement channel which can measure invasive pressure
or temperature.
Measurements
The measurement produces a numeric for temperature; or a real-time pressure wave, together
with the pulse rate and numeric readings for the systolic, diastolic, and mean blood pressure
values.
Temp/Press Features
This illustration shows the user controls and connector for the Temp/Press.
Press Wave
Blood pressure is depicted as a pressure wave with the numerics for systolic, diastolic, and
mean pressure values. The blood pressure shows the cycles of contraction and release within
the heart and the resultant pressure that is generated to move the blood through the vessels.
This illustration is an example of a typical invasive pressure wave.
Connectors for use with a
Temp or a Press
transducer.
100
