Troubleshooting the Installed Instrument
210
Troubleshootin
the Instrument
Troubleshooting the Installed Instrument
Here is a list of some easily corrected troubleshooting cases. If the fault is not described
below, investigate further without delay. For more information, see "Testing the Instrument"
and "Repairing the Instrument".
Troubleshooting with Self-Test Alarm Messages
(When You Switch the Monitor On)
Message What To Do
Battery Low (approxi-
mately 20 minutes remain-
ing)
Connect to AC power to charge the battery, or fit a
fully charged battery within next 15 minutes.
Check Status Log This indicates a non-critical problem in the
Monitor. There is a defect but the Monitor can still
be used.
The Monitor should be investigated technically,
however, as soon as possible.
ECG EQUIP MALF Measurement defective. Exchange the
Measurement Server.
The Measurement Server should be investigated
technically as soon as possible.
NBP EQUIP MALF Measurement defective. Exchange the
Measurement Server.
The Measurement Server should be investigated
technically as soon as possible.
Pressure Zero & Check
Cal
Pressure must be zeroed, or calibration required.
Zero the Pressure, or check the calibration.
If unsuccessful, exchange the Measurement Server.
PRESS EQUIP MALF Measurement defective. Exchange the
Measurement Server or Measurement Server
Extension.
The Measurement Server or Measurement Server
Extension should be investigated technically as
soon as possible.
RESP EQUIP MALF Measurement defective. Exchange the
Measurement Server.
The Measurement Server should be investigated
technically as soon as possible.
