Disassembly Procedures for the M8043A Battery Charger and Conditioner
Re
p
airin
g
the Instrument 239
Disassembly Procedures for the M8043A Battery
Charger and Conditioner
Opening the Housing
Step 1 Disconnect the Battery Charger and Conditioner from AC mains power. Remove
any batteries from the charger.
Step 2 Place the device upside down and remove the five cross-head screws holding the
chassis baseplate.
Step 3 Lift the front edge of the chassis baseplate, then carefully pull it forwards slightly.
Note that some connected cables prevent you from completely removing the
baseplate.
Screws
