Instrument Components
4
Introduction to the Instrument
Instrument Components
The Monitor, the Measurement Server, and Measurement Server Extensions are shown in the
following diagram:
Functional descriptions of these components are to be found later in this chapter.
Measurement Server (M3000A and M3001A)
Monitor (M3046A)
Measurement Server
Extensions
M3016A
M3015A
M3000A has a
gray bezel.
M3001A has a
white bezel.
