phyFLEX boards achieve their small size through modern SMD
technology and multi-layer design. In accordance with the complexity
of the module, 0402-packaged SMD components and laser-drilled
microvias are used on the boards, providing phyFLEX users with
access to this cutting edge miniaturization technology for integration
into their own design.
The phyFLEX-i.MX 6 is a subminiature (60 mm x 70 mm) insert-
ready System on Module populated with the Freescale Semiconductor
i.MX 6 microcontroller. Its universal design enables its insertion in a
wide range of embedded applications.
Precise specifications for the controller populating the board can be
found in the applicable controller reference manual or datasheet. The
descriptions in this manual are based on the Freescale Semiconductor
i.MX 6. No description of compatible microcontroller derivative
functions is included, as such functions are not relevant for the basic
functioning of the phyFLEX-i.MX 6.
The phyFLEX-i.MX 6 offers the following features:
 Subminiature System on Module (60 mm x 70 mm) achieved
through modern SMD technology
 Populated with the Freescale Semiconductor i.MX 6
microcontroller (BGA624 packaging)
 Max. 1.2 GHz core clock frequency
 Boot from different memory devices (NAND Flash (standard))
 phyFLEX bus. Commonly used interfaces such as Ethernet, USB,
UART, SPI, I
2
C, audio, PCIe, SATA, CAN, display and camera
connectivity (both LVDS) are available at up to three high-density
(0.5 mm) samtec connector, enabling the phyFLEX-i.MX 6 to be
plugged like a "big chip" into target application
 Single supply voltage of 5 V
 All controller required supplies generated on board
 Improved interference safety achieved through multi-layer PCB
technology and dedicated ground pins
 1 GB (up to 4 GB) DDR3 SDRAM
 1 GB (up to 16 GB) on-board NAND Flash
