phyFLEX
®
-i.MX 6 [PFL-A-XL1-xxx
14 PHYTEC Messtechnik GmbH 2013 L-773e_2
X1B8
reference-voltage REF_O VDD_SD0 SD0 reference voltage
X1B9 X_SD0_nWP I VDD_SD0
SD0 write protection
(active low)
X1B10 X_SD0_nCD I VDD_SD0
SD0 card detection (active
low)
X1B11 X_SD0_D3 I/O VDD_SD0 SD0 data 3
X1B12 X_SD0_CMD O VDD_SD0 SD0 command
X1B13 GND - - Ground 0 V
X1B14 X_SD0_CLK O VDD_SD0 SD0 clock
X1B15 X_SD0_D0 I/O VDD_SD0 SD0 data 0
X1B16 X_SD0_D1 I/O VDD_SD0 SD0 data 1
X1B17 X_SD0_D2 I/O VDD_SD0 SD0 data 2
X1B18 X_SD0_D4 I/O VDD_SD0 SD0 data 4
X1B19 GND - - Ground 0 V
X1B20 X_SD0_D5 I/O VDD_SD0 SD0 data 5
X1B21 X_SD0_D6 I/O VDD_SD0 SD0 data 6
X1B22 X_SD0_D7 I/O VDD_SD0 SD0 data 7
X1B23 RSVD - - reserved
X1B24
X_ETH0_ANALOG_
VOLTAGE
REF_O VDD_3V3_LOGIC
ETH0 reference voltage
for 10/100 Mbit
X1B25 GND - - Ground 0 V
X1B26 X_ETH0_A+/TX0+ ETH_O VDD_3V3_LOGIC ETH0 data A+ /transmit+
X1B27 X_ETH0_A-/TX0- ETH_O VDD_3V3_LOGIC ETH0 data A-/transmit-
X1B28 X_ETH0_LED0 OC VDD_3V3_LOGIC ETH0 link LED output
X1B29 X_ETH0_B+/RX0+ ETH_I VDD_3V3_LOGIC ETH0 data B+/receive+
X1B30 X_ETH0_B-/RX0- ETH_I VDD_3V3_LOGIC ETH0 data B-/receive-
X1B31 GND - - Ground 0 V
X1B32 X_ETH0_C+ ETH_I/O VDD_3V3_LOGIC ETH0 data C+ (only GbE)
X1B33 X_ETH0_C- ETH_I/O VDD_3V3_LOGIC ETH0 data C- (only GbE)
X1B34 X_ETH0_LED1 OC VDD_3V3_LOGIC ETH0 traffic LED output
X1B35 X_ETH0_D+ ETH_I/O VDD_3V3_LOGIC ETH0 data D+ (only GbE)
X1B36 X_ETH0_D- ETH_I/O VDD_3V3_LOGIC ETH0 data D- (only GbE)
X1B37 GND - - Ground 0 V
X1B38 X_USB0_D- USB_I/O i.MX 6 internal USB0 data-
X1B39 X_USB0_D+ USB_I/O i.MX 6 internal USB0 data+
X1B40 X_USB0_ID I VDD_3V3_LOGIC USB0 ID Pin
X1B41 N.C. - - Not connected
X1B42
.C. - -
ot connecte
X1B43 GND - - Ground 0 V
X1B44 X_USB1_D- USB_/IO i.MX 6 internal USB0 data-
X1B45 X_USB1_D+ USB_I/O i.MX 6 internal USB0 data+
Table 4: Pinout of the phyFLEX-fix Connector X1, Row B (continued)
