4.3.4.2 Forwarding Static
This option allows you to configure the static MAC address forwarding entries on a
specific bridge port. The setting of static MAC address takes effect on egress direction of
bridge port. From the Bridge menu, click on Forwarding and then Forwarding Static. The
following page is displayed.
Forwarding Static
Label Descri
tion
No. From…To…
Select the range of entry number in the FDB to be retrieved. Valid number
value: 1 ~ 512.
Query Click on this button to display the static MAC forwarding entries.
Delete Delete the entries according to the entry number range you type in.
Click on these drop-down list to select a bridge port (ADSL bridge port or
GIGA bridge port) where the static forwarding entries to be configured.
Source MAC Type in the MAC address for the static entry.
VID Type in the VID for the static entry (1 ~ 4094).
Process
Click on the drop-down list and select “Deny” or “Pass”.
"Pass" means to forward the packets with destination MAC address
matching one of the static forwarding MAC addresses to a specified output
bridge port.
"Deny" means to drop the packets.
Create Click on this button to create a new entry.
- 128 -
