4.1.10 IP Routes
This option allows you to configure the IP route table for the in-band management traffic.
From the System menu, click on IP Routes. The following page is displayed:
Click on the drop-down list to select the page to be displayed first.
IP Route Setup
Label Description
System Gateway
This field shows current system default gateway. You can modify the
gateway address by typing in new value and then click on Set.
If the DSLAM is a Slave in a cluster, this field shows the in-band IP address
of the Master; if the DSLAM is a Master in a cluster, this field shows the IP
address of the Cluster gateway.
ADD Next Click on this button to add a new IP route.
Destination Type in the destination IP address for the new IP route.
Net Mask Type in the subnet mask for the new IP route.
Gateway Type in the IP address of the gateway for the new IP route.
Delete Select
Click on the radio button to select a route and then click on Delete to remove
this route from the table.
- 74 -
