4.3.4 Forwarding
4.3.4.1 TP Forwarding DB
This option allows you to retrieve the status of the transparent forwarding database. The
forwarding table will reveal the information of MAC addresses that are learned or
statically configured on a specific bridge port. From the Bridge menu, click on Forwarding
and then TP Forwarding DB. The following page is displayed.
TP Forwarding DB
Label Descri
tion
Aging Time
Type in the aging time in seconds. An entry will be removed from the
FDB (aged-out) if the device does not transmit for a specified period of
time (the aging time).
Modify Click on this button to submit the modification of Aging Time.
No. From…To…
Select the range of entry number in the forwarding database to be
displayed.
Query
Once you have selected the entry number, click on this button to get
most recent status of MAC addresses forwarding.
- 127 -
