4.4 ADSL
4.4.1 Profile
4.4.1.1 Service Main Profile
This option allows you to configure the ADSL line service profile. From the ADSL menu,
click on Profile and then Service Profile(main). The following page is displayed.
ADSL Line Service Profile setup
Label Descri
tion
Select Index
Click on the drop-down list and select the range of profile index. Options
are: 0~10, 11~20, …, 111~120.
Index
This field shows the profile index. Click on the radio button beside the
profile index to select the profile you want to modify or delete. Note that
profile 1 (default) cannot be modified or deleted.
Name Type in the name of the profile.
- 141 -
