4.7.5 Fault Management
4.7.5.1 Alarm/Event
This option allows you to query current alarm, history alarm, and event log. From the
Maintenance menu, click on Fault Management and then Alarm/Event. The Current
Alarm page is displayed. Click on the Alarm/Event Select drop-down list and select
Current Alarm, History Alarm, or Event Log to view.
Current Alarm:
Type in the range of rows (1 ~ 1024) and then click on the Query button.
Current Alarm Table
Label Description
Query Click on this button to get most recent data.
Row This field shows the row number.
ID This field shows the alarm ID.
Description This field shows the description for the alarm.
Level
This field shows the alarm level. Valid values are:
MJ: major alarm. MN: minor alarm.
State This field shows the alarm state: Set or Clear.
Sequential Sequential number.
Time Alarm occurring date and time.
- 184 -
