Step 5 : Connect the ADSL2/2+ CPE to Patch Panel
Connect the ADSL2/2+ CPE to Patch Panel and configure it, the VPI / VCI value must be
the same with IDL-2402.
After finish setting, the CPE will establish the ADSL connection with IDL-2402. You can
check the connection status as below figure. The Current Status is ON.
Now the clients can access to Internet through IDL-2402.
Step 6 : Save the running configuration to Flash
Remember to save your running configuration to the flash, or the settings will be lost if
you power-off IDL-2402.
Go to “Maintenance Æ Database” setting screen, select the “(D) Save Running
Config to Flash (System Config) “. There are two partitions on flash, select your
Partition which you want to save and click “Write Running”. The configuration will save
to the Flash.
Note:
Default Partition is Partition1.
- 31 -
