To make the DSLAM join a cluster, select the Role as “Cluster” or “Slave only” according to your
plan and then click on Modify. The state of the Cluster Configuration will show from
DISCOVERING to VOTING to MASTER or SLAVE at last.
The following figure shows the Cluster Setup page of a cluster containing two cluster members.
You will see the following page if you’re connecting directly to the Master via its in-band IP
address or connecting to the Cluster IP “172.16.77.88”. You can control all the IP DSLAMs in a
cluster by connecting to the Cluster IP address, or by directly connecting to the Master IPDSLAM
via its in-band IP address that is configured in the Board IP Setup page (refer to section 4.1.2).
Cluster Setup
Label Description
Name Type in the NE name in the cluster.
Domain Type in the name of the cluster domain.
Role
Valid options are: Cluster (Master or Slave is decided by the system), Slave only (role of the
DLSAM is always Slave), and Individual (not in a cluster).
Voting Key
Type in 0 or a positive integer as the priority to be Master. 0 means to let system decides
Master and Slaves. If positive integer is typed in, the smaller the number is, the higher priority
- 69 -
