4.3.1.3 ADSL Bridge
This option allows you to setup the ADSL bridge interface. From the Bridge menu, click
on Interface Setup and then ADSL Bridge. The following page is displayed:
You shall click on the drop-down lists to select port range and PVC first. Then the data of
these PVCs (bridge ports) you selected will be displayed. Click on the radio button to
select the bridge port you want to modify.
ADSL Bridge Setup
Label Description
VID Type in the default port VLAN ID. Valid value is 1 ~ 4094.
VLAN
VLAN setting for the egress traffic. Includes three drop-down lists:
UnTagged/Tagged: select untagging/tagging the outgoing frames
(downstream direction for line bridge port). If UnTagged is selected, a
double-tagged packet will leave single-tagged (the outer most VLAN tag is
- 88 -
