INSTALLATION POSSIBILITIES
8 Planmeca Intra X-ray unit
Installation manual
X-ray room with generator box/control panel outside the room (see sections 7
“REMOTE CONTROL PANEL INSTALLATION” on page 48 and 5.3 “Single stud
installation” on page 38)
R
E
A
D
Y
P
R
E
T
mA
kV
s
BW
SELECT
MODE
IR5_1.eps
extension
arm 835mm
r=1975
extension
arm 535mm
r=1675 (std)
extension
arm 385mm
r=1525
extension
arm 760mm
r=1900 (std)
Generator box
Remote control panel
Telephone cable,
max. 12 m
IR6_1.eps
R
EA
D
Y
PRET
m
A
k
V
s
B
W
S
E
L
E
C
T
M
O
D
E
extension
arm 835mm
r=1975
extension
arm 535mm
r=1675 (std)
extension
arm 385mm
r=1525
extension
arm 760mm
r=1900
Generator box
Extension cable,
max. 12 m
