STANDARD INSTALLATION TO A WALL
22 Planmeca Intra X-ray unit
Installation manual
4.7 Attaching the control panel holder to the generator housing
Drill two ø3.5-4mm (0.14-0.16 in.) holes for the control panel holder to the generator housing. The
hole positions are marked to the inner side of the cover with collars.
Attach the control panel holder to the generator housing with the two PT 3x22 rst WN1451 screws.
1
2
3
4
5
6
ins14.eps
Generator housing
Ins15.eps
Control panel holder
Generator housing
