Planmeca intra Installation Manual

FINAL ADJUSTMENTS
60 Planmeca Intra X-ray unit Installation manual
11.3Adjusting the stiffness of the tube head’s horizontal axle
Remove the plug from the tube head’s axle and adjust the tightness of the two adjusting screws
evenly (arrows on the figure below).
Adj_stiffness.eps
WARNING!
Do not touch the painted screws
ø 2.5 Allen screw
or the earth spring attachment screw.

Planmeca intra Specifications

General

Manufacturer	Planmeca
Model	Planmeca Intra
Frequency	50/60 Hz
Tube Voltage	60-70 kV
Tube Current	7 mA
Type	Dental X-ray Unit
Voltage	100-240 V
Weight	Varies depending on configuration; refer to specific model documentation
