Planmeca Intra X-ray unit 1
INTRODUCTION
Installation manual
1 INTRODUCTION
This manual contains all the information required to install and set up the Planmeca Intra X-ray unit.
Please read this manual carefully before installing the X-ray unit.
WARNING
Failure to install the Planmeca Intra X-ray unit in an approved location may
be dangerous to both patient and operator.
CAUTION
It is very important that the room in which the Planmeca Intra X-ray unit is
installed and the position from which the equipment is operated are
correctly shielded against radiation.
Since radiation safety requirements vary from country to country and state
to state, it is the responsibility of the installer to ensure that all local and
national safety regulations are met.
NOTE In case the Planmeca Dixi digital intra X-ray system is going to be installed
to the Planmeca Intra X-ray unit, use the Dixi digital intra X-ray system
installation manual in conjunction with this manual.
The manufacturer, assembler and importer are responsible for the safe-
ty, reliability and performance of the X-ray only if:
- installation, calibration, modification and repairs are carried out by qual-
ified and authorized personnel
- electrical installations are carried out according to the appropriate re-
quirements such as IEC364
- equipment is used according to the operating instructions
Planmeca pursues a policy of continual product development. Although every
effort is made to produce up-to-date product documentation this publication
should not be regarded as an infallible guide to current specifications. We re-
serve the right to make changes without prior notice.
COPYRIGHT PLANMECA 2
008-03
PUBLICATION PART NUMBER 10006030 revision 1
1

Planmeca intra Specifications

General

Manufacturer	Planmeca
Model	Planmeca Intra
Frequency	50/60 Hz
Tube Voltage	60-70 kV
Tube Current	7 mA
Type	Dental X-ray Unit
Voltage	100-240 V
Weight	Varies depending on configuration; refer to specific model documentation
