Fault code Possible cause Fault isolating / repair
32.Side jogger, hall sensor
SEN7, faulty. Sensor defective. Check that the voltage between 15C and
19A on connector J1. Is greater than 2.2
VDC with the sensor blocked and less
than 0.9 VDC with the sensor unblocked.
Wires defective. Disconnect the sensor connector. Check
the wires for an open circuit using a
voltmeter. Measure on connector J1
between 15C and 19A. And between 19A
and 1A.
Controller PCB defective. If check above is good, replace the
controller PCB.
Continue FIP 8.1 Self diagnostic system control, Fault code table
Bookletmaker SR 85 PAGE 8.1.9 August 2000
