Polaris 850 MATRYX INDY XC 129 2021

3.146
9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
AIR BOX INSTALLATION
1. Reinstall the air box assembly. Tighten air box-to-
throttle body gear clamps
2!
to specification.
TORQUE
Air Box Throttle Body Gear Clamps:
11 in-lbs (1.24 N·m)
NOTICE
If the ignition coils were removed, reinstall the ignition
coils and torque fasteners to specification.
TORQUE
Air Box Coil Fasteners:
36 in-lbs (4 N·m)
2. Install new cable tie on air box routing clip
2)
to
secure the stator wiring harness and throttle cable.
3. Connect the ignition coil connectors
l
to the wire
harness and install the spark plug caps
1(
onto the
spark plugs.
4. Connect the T-MAP Sensor
k
to the wiring harness
and install new cable tie
j
to secure wiring.
ENGINE / COOLING / EXHAUST
