9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
SHOCKS
GENERAL
SHOCK REBUILDING TOOLS
Gas Shock Recharging Kit
2200421
Gas Fill Tool
PS-45259
Gas Shock Fill
PU-51039
Gas Fill Tool Replacement Needles
(20 Pack)
PS-45259-1
Shock Body Holding Tool (1 3/4”)
PS-45629
Shock Body Holding Tool (1 5/8”)
2871071
Shock Body Holding Tool (2 1/8”)
PS-45281
Shock Rod Holding Tool 1/2"
Diameter Rod
2871352
Shock Rod Holding Tool 5/8"
Diameter Rod
2872429
STEERING / SUSPENSIONS
