BUMPER ASSEMBY VIEWS
FRONT BUMPER ASSEMBLY VIEW
q
Front Bumper
y
Bumper Mounting Nuts
7 ft-lbs (10 N·m)
w
RH 1/4 Turn Mount
u
LH 1/4 Turn Mount
e
Rivet
i
Front Lower Bumper
r
Bumper Mounting Fasteners
o
Bumper / Nosepan Fasteners:
7 ft-lbs (10 N·m)
t
Pipe / Chassis Bracket
CHASSIS
