THROTTLE POSITION SENSOR (TPS) WIRE ROUTING
The throttle position sensor (TPS) is not serviceable. If the TPS fails or is out of specification, replace the entire throttle
body assembly. For additional information regarding throttle body removal see the following procedures:
• Throttle Body Removal
• Throttle Body Installation
NOTICE
Anytime the throttle body is serviced, follow the TPS wire lead routing information below.
1. From the throttle position sensor (TPS), route the TPS wire lead back along the sensor and secure the wire lead to
the sensor with a panduit strap
q
.
ENGINE ELECTRICAL
