9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
3.155
EXHAUST INSTALLATION
1. Install the Exhaust Seal, Socket
q
.
NOTICE
Inspect; replace if damaged.
2. Inspect the tuned pipe and the rubber pipe mount.
3. Set the tuned pipe in place.
4. From the right rear of the bellypan, install the bottom
exhaust spring
w
that connects tuned pipe to exhaust
manifold.
NOTICE
Stainless steel (gray) springs connect the tuned pipe to
the exhaust manifold.
An extended length exhaust spring tool aids in lower
exhaust spring removal/installation.
5. Install the upper exhaust springs
e
.
NOTICE
Stainless steel (gray) springs connect the tuned pipe to
the exhaust manifold.
ENGINE / COOLING / EXHAUST
