8.105
19.To service the reservoir, remove the reservoir tube
from the shock bridge. Discard the O-ring.
20.The clicker knob can be serviced by removing the
screw and knob.
21.Optional service: Remove the clicker assembly from
the shock bridge.
NOTICE
Servicing the clicker assembly is difficult without the
proper tools.
22.Optional service: Disassemble the clicker assembly
as shown. Discard all O-rings and replace with new.
NOTICE
Clicker compression washers may differ from shock to
shock. See specification tables for washer settings.
23.Discard all O-rings and wear bands from removed
components.
24.Clean the shock components with parts cleaner. Blow
dry with compressed air.
STEERING / SUSPENSIONS
