9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
10.7
ELECTRICAL HARNESS
CHASSIS HARNESS COMPONENT LOCATIONS
q
Electric start
h
Load Center
2(
TMAP Sensor
w
Injector Harness
j
Chassis Ground 3)
LED Handguard Accent
e
Ground Speed Sensor
k
EGT Sensor 3!
Front Work Light Switch
r
Fuel Sensor l
Diagnostic Power Test Jumper
3@
Tether Switch
t
EGT 2 Sensor 1(
Diagnostic Power Connector
3#
VCM
y
PBR (DC Power)
2)
Front Work Light
3$
Driver Seat Heater Switch
u
Chassis / Hood
2!
Digital Wrench
3%
Fuel Pump
i
Stator Signals
2@
CAN2 Data Enable
3^
Rear Harness
o
Ferrite Suppressor
2#
Logger Switch
3&
Ignition Switch
a
Ignition Coil (MAG)
2$
Oil Level
3*
Handlebar Connection
s
Ignition Coil (PTO)
2%
Ground Speed Capacitor
3(
Left Hand Controls
d
ECU Connector B
2^
Detonation Sensor
4)
RCA Accessory Power
f
ECU Connector A
2&
Coolant Temp Sensor
4!
Oil Pump
g
EV Actuator 2*
PBR (ECU, CAN, GND)
4@
TPS Sensor
BATTERY / ELECTRICAL
