9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
10.27
6. Connect the handlebar connections connector
r
and
left hand controls connector
t
from the main
harness. Make sure the connectors get secured to
the air box with the Christmas tree clips on the
connectors.
7. Place console switch panel
w
near its installed
position and connect the main harness key switch
connector to the key switch
e
.
8. Install the two push rivets securing the console switch
panel.
IMPORTANT
If the left hand control was replaced, the CALIBRATE
ALL option in DW is needed.
BATTERY / ELECTRICAL
