ELECTRIC START / BATTERY BULLET CONNECTORS
1. The electric start harness battery power bullet connector should be connected to the female bullet connector as
shown
q
.
2. Connect the electric start harness battery negative bullet connector to the female bullet connector as shown
w
.
3. Make sure the electric start harness is routed along the right footrest and secured in the edge clip / panduit in the
location shown
e
.
