Power Electronics SD700 Series User Manual

SD700
POWER ELECTRONICS
98
CONFIGURATION REGISTER
PARAMETERS
FACTORY SETTINGS
SETTING 1
SETTING 2
3 Kp Tq = 95%
95%
___________________
___________________
4 Ki Tq = 95%
95%
___________________
___________________
5 Kp I = 95%
95%
___________________
___________________
6 Ki I = 15%
15%
___________________
___________________
9 Flux tune = 2.0%
2.0%
___________________
___________________
G20: Communication Buses – S20.0: Communications Control
1 COM. CONTROL=0
0
G20: Communication Buses – S20.1: Modbus RTU
1 COMMS T/O=OFF
COMMS TIMEOUT
OFF
___________________
___________________
2 COMM ADDR=10
COMM ADDRESS
10
___________________
___________________
3 BAUDS=9600
9600
___________________
___________________
4 PARITY=NONE
NONE
___________________
___________________
G20: Communication Buses – S20.2: PROFIBUS
1 NODE ADDR=10
NODE ADDRESS
10
___________________
___________________
G20: Communication Buses – S20.3: CANOPEN
1 CO NODEID=0
0
___________________
___________________
2 CO BAUD=1Mbps
1Mbps
___________________
___________________
3 CO REF sp=+0.0%
+0.0%
___________________
___________________
G20: Communication Buses – S20.4: DEVICENET
1 DN MACID=0
0º
___________________
___________________
2 DNBaud=500kbps
500kbps
___________________
___________________
3 CONTROL MODE=0
0
___________________
___________________
4 REFEREN MODE=0
0
___________________
___________________
5 FAULT MODE = PE BEHV
PE BEHV
___________________
___________________
6 ASM IN=70
70º
___________________
___________________
7 ASM- OUT=20
20º
___________________
___________________
8 DNst=UNUSED
UNUSED
___________________
___________________
G20: Communication Buses – S20.5: OFC
1 B/R F.O = 1 Mbps
1 Mbps
___________________
___________________
G20: Communication Buses – S20.6: Registers
01 Reg01 = 40001
40001
___________________
___________________
02 Reg02 = 40001
40001
___________________
___________________
03 Reg03 = 40001
40001
___________________
___________________
04 Reg04 = 40001
40001
___________________
___________________
05 Reg05 = 40001
40001
___________________
___________________
06 Reg06 = 40001
40001
___________________
___________________
07 Reg07 = 40001
40001
___________________
___________________
